Alfa Romeo Alfetta CEM

MODEL YEAR: 1982

Data Quality

B

Contributors

rover rover

Park in your virtuagarage

Add to your virtuagarage

In the 80's Alfa Romeo did the first experiments to reduce fuel consumption, working on a device that would then find a certain diffusion a fortnight later: the cylinder deactivation. The CEM (Controllo Elettronico del Motore) is the implementation of the Electronic Engine Control technology, studied with the University of Genoa since 1976.
The CEM's control unit had a 6-kb memory microprocessor, which allowed to store two operating maps; The basic engine was the same Alfa America, which was already the originator of the Bosch Motronic electronic injection. The modifications included some sensors that monitored the engine's operation and enabled 2 cylinders of 4  to be switched off depending on some condition. The shutdown occurred from the minimum speed up to 2,800 rpm. This meant that you could get to 100 km / h without using all four cylinders with a consumption dropped from 12 to 25% depending on the type of use. With less of 1000 copies of Alfetta CEM this experimental technology wasn't followed for the large-scale production.

General

Complete name of the carAlfa Romeo Alfetta CEM
Model year1982
year (from)1982
year (to)1984
Total production994
Quality of DataB - Almost perfect

Specifications

Body styleSedan
no.Doors4
Wheelbase2510 mm
Lenght4385 mm
Width1640 mm
Height1430 mm
Curb Weight1140 kg
Wheel DriveRear
Engine LocationFront
Seating capacity (number)5
Track Tread (front)1366 mm
Track Tread (rear)1358 mm
Engine AlignmentLongitudinal
Fuel capacity49 l

Engine / Powertrain

Kind of EngineNaturally aspirated
Cylinders ConfigurationStraight/Inline Engine
Displacement1962 cc
Cylinders number4
Valve TrainDouble overhead camshaft DOHC
Bore84 mm
Stroke88.5 mm
Maximum Power (HP)130 hp
Power (PS)124 PS
Power kW95 kW
Power @ rounds per minute5300 rpm
Torque178 Nm
Torque @ r.p.m.4000 rpm
Compression Ratio1:1
FuelPetrol
CoolantWater

Drivetrain & Suspension

Suspensions FrontInd. suspensions secured to the frame by inclined transverse wishbones, Independent, Telescopic shock absorbers, Torsion bar
Suspensions RearAnti Roll Bar, Coil springs, de Dion axle, hydraulic telescopic dampers, parallel linkage (Watt's)
Front BrakesDisc
Rear BrakesDisc
Transmission type5 speed manual
Front tyres dimensions185/70HRx14
Rear tyres dimensions185/70HRx14
Fuel capacity49 l
SteeringRack and pinion

Performances

Top Speed180 km/h
Consumption mixed8.6 l/100km

Cars mounting the same engine (produced by Alfa Romeo)

Alfa Romeo Alfetta 2.0i Quadrifoglio Oro II (tipo 116.55N)
  1. Alfa Romeo Alfetta MK1
    1972 > 1976 GEN
