Chrysler PT Cruiser

Engines

9

Id.Engine	2148 cc
Kind of Engine	Turbocharged
Identificative engine
Cylinders Configuration	Straight/Inline Engine
Displacement	2148 cc
Cylinders number	4
Fuel	Diesel
Electric engine - kind
Battery kind
Peak Power (hp)
Peak Power (kW)
Battery power
Operating Voltage
Battery: Operating Temperature
Battery: System Voltage
Battery: Cell Configuration
Battery: 0-80% Charge time
Torque	300 N-m
Torque @ r.p.m.	1600-2600 rpm
Cylinders angle
Maximum Power (HP)	119 hp
Power (PS)	121 ps
Power kW	89 kW
Power @ rounds per minute	4200 rpm
Bore	88 mm
Stroke	88.3 mm
Valve Train	Double overhead camshaft DOHC
Compression Ratio	18:1
Engine block material
Cylinder head material
Fuel System	common rail diesel injection
Coolant	Water
Engine Data accuracy
	PT Cruiser CRD 1

Id.Engine	1598 cc	1995 cc	2429 cc	2429 cc	2429 cc	2429 cc	2429 cc	2429 cc
Kind of Engine	Naturally aspirated	Naturally aspirated		Naturally aspirated	Turbocharged		Turbocharged	Turbocharged
Identificative engine
Cylinders Configuration	Straight/Inline Engine	Straight/Inline Engine	Straight/Inline Engine	Straight/Inline Engine	Straight/Inline Engine	Straight/Inline Engine	Straight/Inline Engine	Straight/Inline Engine
Displacement	1598 cc	1995 cc	2429 cc	2429 cc	2429 cc	2429 cc	2429 cc	2429 cc
Cylinders number	4	4	4	4	4	4	4	4
Fuel	Petrol	Petrol	Petrol	Petrol	Petrol	Petrol	Petrol	Petrol
Electric engine - kind
Battery kind
Peak Power (hp)
Peak Power (kW)
Battery power
Operating Voltage
Battery: Operating Temperature
Battery: System Voltage
Battery: Cell Configuration
Battery: 0-80% Charge time
Torque	157 N-m	188 N-m	227 N-m	224 N-m	285 N-m	339 N-m	332 N-m	332 N-m
Torque @ r.p.m.	4550 rpm	4150 rpm	4200 rpm	4000 rpm	2800-4000 rpm	3600 rpm	2800-4500 rpm	2800-4500 rpm
Cylinders angle
Maximum Power (HP)	113 hp	140 hp		150 hp	180 hp		220 hp	230 hp
Power (PS)	115 ps	142 ps	150 ps	152 ps	183 ps	215 ps	223 ps	233 ps
Power kW	84 kW	104 kW		112 kW	134 kW		164 kW	172 kW
Power @ rounds per minute	5600 rpm	5700 rpm	5500 rpm	5100 rpm	5200 rpm	5000 rpm	5100 rpm	5100 rpm
Bore	77 mm	87.5 mm	87 mm	87.5 mm	87.5 mm		87.5 mm	87.5 mm
Stroke	85.8 mm	83 mm	101 mm	101 mm	101 mm		101.4 mm	101.4 mm
Valve Train	Single overhead camshaft SOHC	Double overhead camshaft DOHC		Double overhead camshaft DOHC	Double overhead camshaft DOHC		Double overhead camshaft DOHC	Double overhead camshaft DOHC
Compression Ratio	10.5:1	9.6:1		9.5:1	8.1:1		8.1:1	8.1:1
Engine block material
Cylinder head material
Fuel System	efi	efi		smpfi	smpfi		smpfi	smpfi
Coolant	Water	Water		Water	Water		Water	Water
Engine Data accuracy
	PT Cruiser 1.6 1	PT Cruiser 1	PT Cruiser 1 PT Cruiser Automatic 1	PT Cruiser Convertible Automatic 1 PT Cruiser Convertible 1	PT Cruiser Convertible Limited Turbo 1	PT Cruiser Turbo 1 PT Cruiser Turbo Automatic 1	PT Cruiser Turbo Automatic 1 PT Cruiser Turbo 1	PT Cruiser GT Turbo 1 PT Cruiser GT Turbo Automatic 1

Car body variants

2 CVT MPV

Variants	#CVT	#MPV	#MPV	#MPV	#MPV
Body style	Convertible/Cabrio/Cabriolet	Multi Purpose Vehicle	Multi Purpose Vehicle	Multi Purpose Vehicle	Multi Purpose Vehicle
no.Doors
Wheelbase	2616 mm	2616 mm	2616 mm	2616 mm	2616 mm
Lenght	4290 mm	4288 mm	4288 mm	4288 mm	4290 mm
Width	1704 mm	1704 mm	1704 mm	1705 mm	1704 mm
Height	1539 mm	1601 mm	1600 mm	1601 mm	1600 mm
Curb Weight
Wheel Drive
Engine Location	Front	Front	Front	Front	Front
Chassis
Seating capacity (number)
Track Tread (front)	1476 mm	1481 mm	1481 mm	1481 mm	1481 mm
Track Tread (rear)	1478 mm	1478 mm	1478 mm	1478 mm	1478 mm
Luggage capacity (min)
Luggage capacity (max)
Weight distribution (FRONT)
Engine Alignment	Transverse	Transverse	Transverse	Transverse	Transverse
Drag Coefficient
Equipment
	PT Cruiser Convertible Limited Turbo PT Cruiser Convertible Automatic PT Cruiser Convertible	PT Cruiser CRD PT Cruiser 1.6	PT Cruiser Turbo Automatic PT Cruiser Turbo	PT Cruiser PT Cruiser PT Cruiser Automatic PT Cruiser Turbo PT Cruiser Turbo Automatic	PT Cruiser GT Turbo PT Cruiser GT Turbo Automatic
