About this car
Trim Levels/Versions
5| Year | Model Name | Fuel | Body | WheelDrive | Pr.From | to | Speed | QOD | |
|---|---|---|---|---|---|---|---|---|---|
| Year | Model Name | Fuel | Body | WheelDrive | Pr.From | to | Speed | QOD | |
| 1979 | Citroën Dyane 6 | Petrol | Sedan | UNK | 0 | 0 | 120 km/h |
E
|
|
| 1978 | Citroën Dyane 6 Weekend | Petrol | Station Wagon / Estate | UNK | 0 | 0 | - |
E
|
|
| 1967 | 1967 Citroën Dyane 4 | Petrol | Sedan | UNK | 0 | 0 | - |
E
|
|
| 1967 | 1967 Citroën Dyane 6 | Petrol | Sedan | UNK | 0 | 0 | - |
E
|
|
| 1978 | Citroën Acadiane (1978) | Petrol | Van | UNK | 0 | 0 | - | 1 |
D
|
Engines
2
»
Petrol Engines
| Id.Engine | 435 cc | 602 cc |
|---|---|---|
| Kind of Engine | Naturally aspirated | Naturally aspirated |
| Identificative engine | ||
| Cylinders Configuration | Boxer/Flat Engine | Boxer/Flat Engine |
| Displacement | 435 cc | 602 cc |
| Cylinders number | 2 | 2 |
| Fuel | Petrol | Petrol |
| Electric engine - kind | ||
| Battery kind | ||
| Peak Power (hp) | ||
| Peak Power (kW) | ||
| Battery power | ||
| Operating Voltage | ||
| Battery: Operating Temperature | ||
| Battery: System Voltage | ||
| Battery: Cell Configuration | ||
| Battery: 0-80% Charge time | ||
| Torque | 28 N-m | 41 N-m |
| Torque @ r.p.m. | 3750 rpm | 4000 rpm |
| Cylinders angle | ||
| Maximum Power (HP) | 24 hp | 32 hp |
| Power (PS) | 24.3 ps | 32.4 ps |
| Power kW | 17.9 kW | 23.9 kW |
| Power @ rounds per minute | 6750 rpm | 5750 rpm |
| Bore | 68.5 mm | 74 mm |
| Stroke | 59 mm | 70 mm |
| Valve Train | Overhead valves OHV | Overhead valves OHV |
| Compression Ratio | 8.5:1 | 9:1 |
| Engine block material | ||
| Cylinder head material | ||
| Fuel System | 1 solex carburettor | 1 solex carburettor |
| Coolant | Air | Air |
| Engine Data accuracy | ||
|
Dyane 4
1
|
Dyane 6
1
Dyane 6 Weekend 1 Dyane 6 1 Acadiane 5 |
Car body variants
3 SED SWG VAN| Variants | #SED | #SED | #SWG | #VAN |
|---|---|---|---|---|
| Body style | Sedan | Sedan | Station Wagon / Estate | Van |
| no.Doors | ||||
| Wheelbase | 2400 mm | 2400 mm | 2400 mm | 2535 mm |
| Lenght | 3870 mm | 3930 mm | 3874 mm | 3870 mm |
| Width | 1500 mm | 1500 mm | 1499 mm | 1500 mm |
| Height | 1540 mm | 1556 mm | 1537 mm | 1835 mm |
| Curb Weight | ||||
| Wheel Drive | ||||
| Engine Location | Front | Front | Front | Front |
| Chassis | ||||
| Seating capacity (number) | ||||
| Track Tread (front) | 1260 mm | 1270 mm | 1260 mm | |
| Track Tread (rear) | 1260 mm | 1270 mm | 1260 mm | |
| Luggage capacity (min) | ||||
| Luggage capacity (max) | ||||
| Weight distribution (FRONT) | ||||
| Engine Alignment | ||||
| Drag Coefficient | ||||
| Equipment | ||||
|
Dyane 6
|
Dyane 4
Dyane 6 |
Dyane 6 Weekend
|
Acadiane
|
