1948 Fiat 500 B
MODEL YEAR: 1948
Data Quality
E
Contributors
No revisions
Park in your virtuagarage
General
| Complete name of the car | 1948 Fiat 500 B |
|---|---|
| Model year | 1948 |
| Quality of Data | E - Most field Uncomplete |
Specifications
| Body style | Sedan |
|---|---|
| no.Doors | 2 |
| Wheelbase | 2000 mm |
| Lenght | 3210 mm |
| Width | 1273 mm |
| Height | 1375 mm |
| Curb Weight | 790 kg |
| Wheel Drive | Missing info |
| Engine Location | Front |
| Seating capacity (number) | 2 |
| Track Tread (front) | 1116 mm |
| Track Tread (rear) | 1083 mm |
| Engine Alignment | Longitudinal |
Engine / Powertrain
| Kind of Engine | Naturally aspirated |
|---|---|
| Cylinders Configuration | Straight/Inline Engine |
| Displacement | 569 cc |
| Cylinders number | 4 |
| Valve Train | Overhead valves OHV |
| Bore | 52 mm |
| Stroke | 67 mm |
| Maximum Power (HP) | 16.5 hp |
| Power (PS) | 16.7 PS |
| Power kW | 12.3 kW |
| Power @ rounds per minute | 4000 rpm |
| Fuel | Petrol |
| Coolant | Water |
Drivetrain & Suspension
| Suspensions Front | Independent, Wishbones, Macpherson strut with Wishbone |
|---|---|
| Suspensions Rear | Live axle, Macpherson strut with Wishbone |
| Front Brakes | Drum |
| Rear Brakes | Drum |
| Transmission type | 4 speed manual |
| Wheel Size (front) | 15 x 2.50c |
| Wheel Size (rear) | 15 x 2.50c |
| Front tyres dimensions | 4.25-15 |
| Rear tyres dimensions | 4.25-15 |
