Ford GT40

Year	Model Name	Fuel	Body	WheelDrive	Pr.From	to	Speed	QOD
Year	Model Name	Fuel	Body	WheelDrive	Pr.From	to	Speed	QOD
1965	1965 Ford GT40 Mk I	Petrol	Coupé	RWD	0	0	321 km/h	E
1966	1966 Ford GT40 Mk III	Petrol	Coupé	RWD	0	0	257 km/h	E
1966	1966 Ford GT40 Mk II	Petrol	Coupé	RWD	0	0	329 km/h	E
1967	Ford GT40 Mk IV	Petrol	Coupé	RWD			354.1 km/h	E

» Petrol Engines

Id.Engine	4727 cc	4736 cc	6997 cc	6997 cc
Kind of Engine	Naturally aspirated	Naturally aspirated	Naturally aspirated	Naturally aspirated
Identificative engine
Cylinders Configuration	V Engine	V Engine	V Engine	V Engine
Displacement	4727 cc	4736 cc	6997 cc	6997 cc
Cylinders number	8	8	8	8
Fuel	Petrol	Petrol	Petrol	Petrol
Electric engine - kind
Battery kind
Peak Power (hp)
Peak Power (kW)
Battery power
Operating Voltage
Battery: Operating Temperature
Battery: System Voltage
Battery: Cell Configuration
Battery: 0-80% Charge time
Torque
Torque @ r.p.m.
Cylinders angle
Maximum Power (HP)	306 hp	385 hp		485 hp
Power (PS)	310 ps
Power kW	228 kW		500 kW
Power @ rounds per minute	6000 rpm	7000 rpm	6400 rpm	6200 rpm
Bore	101.6 mm	101.6 mm	107.7 mm
Stroke	72.9 mm	72.9 mm	96.1 mm
Valve Train	Overhead valves OHV	Overhead valves OHV	Overhead valves OHV	Overhead valves OHV
Compression Ratio	10.9:1	10		10.5
Engine block material
Cylinder head material
Fuel System	1 ho carburettor	4 weber carburettors		4 weber carburettors
Coolant	Water	Water	Water	Water
Engine Data accuracy				D
	GT40 Mk III 1	GT40 1	GT40 Mk IV 5	GT40 1

1 COU

Variants	#COU	#COU	#COU	#COU
Body style	Coupé	Coupé	Coupé	Coupé
no.Doors
Wheelbase	2413 mm	2413 mm	2423 mm	2413 mm
Lenght	4028 mm	4140 mm	4293 mm	4343 mm
Width	1778 mm	1778 mm	1778 mm	1791 mm
Height	1029 mm	1028 mm	1041 mm	978 mm
Curb Weight
Wheel Drive
Engine Location	Middle	Middle	Middle	Middle
Chassis
Seating capacity (number)
Track Tread (front)	1397 mm	1448 mm	1353 mm	1397 mm
Track Tread (rear)	1397 mm	1448 mm	1372 mm	1392 mm
Luggage capacity (min)
Luggage capacity (max)
Weight distribution (FRONT)
Engine Alignment	Longitudinal	Longitudinal	Longitudinal	Longitudinal
Drag Coefficient
Equipment
	GT40	GT40	GT40 Mk III	GT40 Mk IV
