Renault Rodéo 5

MODEL YEAR: 1981

Data Quality

Contributors

No revisions

Park in your virtuagarage

Makes » Renault » Renault Rodéo 5

From September 1981, Renault introduced a new model with a more modern body design, the Rodéo 5 (with the name now reversed when combined with the Renault branding). This model was based on the Renault 4 GTL and featured more compact dimensions. Still equipped with the 1,108 cm³ engine, it was manufactured by Teilhol, the new name for ACL since July 1978.

Production of this model ceased in October 1986: it was considered a partial failure and did not have a successor in the Renault lineup.

General

Complete name of the car	Renault Rodéo 5
Model year	1981
year (from)	1981
year (to)	1986
Quality of Data	B - Almost perfect

Specifications

Body style	Convertible/Cabrio/Cabriolet
no.Doors	2
Wheelbase	2430 mm
Lenght	3560 mm
Width	1490 mm
Height	1510 mm
Curb Weight	720 kg
Wheel Drive	Front
Engine Location	Front
Seating capacity (number)	4/5
Track Tread (front)	1280 mm
Track Tread (rear)	1250 mm
Engine Alignment	Longitudinal
Fuel capacity	34 l

Engine / Powertrain

Cylinders Configuration	Straight/Inline Engine
Displacement	1108 cc
Cylinders number	4
Bore	70 mm
Stroke	72 mm
Power (PS)	34 PS
Power @ rounds per minute	4000 rpm
Torque	75 Nm
Torque @ r.p.m.	2500 rpm
Compression Ratio	1:1
Fuel	Petrol
Engine Data accuracy	D

Drivetrain & Suspension

Suspensions Front	Wishbones, Independent, Anti Roll Bar, Torsion bar, Telescopic damper struts
Suspensions Rear	Independent, Torsion bar, Telescopic damper struts, Swinging longitudinal trailing arms
Front Brakes	Disc
Rear Brakes	Drum
Transmission type	4 speed manual
Fuel capacity	34 l
Steering	Rack and pinion
