1997 > 2001
1997 > 2001
| Year | Model Name | Fuel | Body | WheelDrive | Pr.From | to | Speed | QOD | |
|---|---|---|---|---|---|---|---|---|---|
| Year | Model Name | Fuel | Body | WheelDrive | Pr.From | to | Speed | QOD | |
| 1997 | 1997 Alfa Romeo 156 V6 | Petrol | Sedan | FWD | 0 | 0 | - |
|
|
| 1998 | Alfa Romeo 156 Sportwagon 1.6 Twin Spark 16v | Petrol | Station Wagon / Estate | FWD | 1998 | 2001 | 200 km/h |
D
|
|
| 1997 | 1997 Alfa Romeo 156 Sportwagon 1.9 JTD | Diesel | Station Wagon / Estate | FWD | 1997 | 2001 | 188 km/h |
C
|
|
| 1998 | Alfa Romeo 156 Sportwagon 2.0 T. Spark | Petrol | Station Wagon / Estate | FWD | 1998 | 2001 | 208 km/h |
|
|
| 1998 | Alfa Romeo 156 Sportwagon 2.4 JTD | Diesel | Station Wagon / Estate | FWD | 1997 | 2001 | 203 km/h |
|
|
| 2000 | 2000 Alfa Romeo 156 Sportwagon 2.5 V6 24v | Petrol | Station Wagon / Estate | FWD | 0 | 0 | 230 km/h |
|
|
| 2000 | 2000 Alfa Romeo 156 Sportwagon 2.5 V6 Q-System | Petrol | Station Wagon / Estate | FWD | 0 | 0 | 227 km/h |
|
|
| 1998 | Alfa Romeo 156 Sportwagon 1.8 Twin Spark 16v | Petrol | Station Wagon / Estate | FWD | 1998 | 2001 | 210 km/h |
|
|
| 1998 | 1998 Alfa Romeo 156 V6 Q-System | Petrol | Sedan | AWD | 0 | 0 | 227 km/h |
|
|
| 1997 | 1997 Alfa Romeo 156 2.0 Twin Spark | Petrol | Sedan | FWD | 0 | 0 | 208 km/h |
|
|
| 1997 | 1997 Alfa Romeo 156 1.9 JTD | Diesel | Sedan | FWD | 0 | 0 | 188 km/h |
|
|
| 1997 | 1997 Alfa Romeo 156 1.8 Twin Spark 16v | Petrol | Sedan | FWD | 0 | 0 | 210 km/h |
|
|
| 1997 | 1997 Alfa Romeo 156 1.6 Twin Spark 16v | Petrol | Sedan | FWD | 1997 | 2001 | 200 km/h |
C
|
|
| 1997 | 1997 Alfa Romeo 156 2.4 JTD | Diesel | Sedan | FWD | 0 | 0 | - |
|
| Id.Engine | 1910 cc | 2387 cc |
|---|---|---|
| Kind of Engine | ||
| Identificative engine | ||
| Cylinders Configuration | Straight/Inline Engine | Straight/Inline Engine |
| Displacement | 1910 cc | 2387 cc |
| Cylinders number | 4 | 5 |
| Fuel | Diesel | Diesel |
| Electric engine - kind | ||
| Battery kind | ||
| Peak Power (hp) | ||
| Peak Power (kW) | ||
| Battery power | ||
| Operating Voltage | ||
| Battery: Operating Temperature | ||
| Battery: System Voltage | ||
| Battery: Cell Configuration | ||
| Battery: 0-80% Charge time | ||
| Torque | 255 N-m | 305 N-m |
| Torque @ r.p.m. | 2000 rpm | 2000 rpm |
| Cylinders angle | ||
| Maximum Power (HP) | ||
| Power (PS) | 105 ps | 136 ps |
| Power kW | ||
| Power @ rounds per minute | 4000 rpm | 4200 rpm |
| Bore | 83 mm | 82 mm |
| Stroke | 90 mm | 90 mm |
| Valve Train | ||
| Compression Ratio | ||
| Engine block material | ||
| Cylinder head material | ||
| Fuel System | ||
| Coolant | ||
| Engine Data accuracy | ||
|
156 Sportwagon 1.9 JTD
1
156 1.9 JTD 1 |
156 Sportwagon 2.4 JTD
1
156 2.4 JTD 1 |
| Id.Engine | 1598 cc | 1747 cc | 1970 cc | 2492 cc | 2492 cc |
|---|---|---|---|---|---|
| Kind of Engine | Naturally aspirated | Naturally aspirated | Naturally aspirated | ||
| Identificative engine | |||||
| Cylinders Configuration | Straight/Inline Engine | Straight/Inline Engine | Straight/Inline Engine | V Engine | V Engine |
| Displacement | 1598 cc | 1747 cc | 1970 cc | 2492 cc | 2492 cc |
| Cylinders number | 4 | 4 | 4 | 6 | 6 |
| Fuel | Petrol | Petrol | Petrol | Petrol | Petrol |
| Electric engine - kind | |||||
| Battery kind | |||||
| Peak Power (hp) | |||||
| Peak Power (kW) | |||||
| Battery power | |||||
| Operating Voltage | |||||
| Battery: Operating Temperature | |||||
| Battery: System Voltage | |||||
| Battery: Cell Configuration | |||||
| Battery: 0-80% Charge time | |||||
| Torque | 144 N-m | 169 N-m | 187 N-m | 222 N-m | 222 N-m |
| Torque @ r.p.m. | 4500 rpm | 3500 rpm | 3500 rpm | 5000 rpm | 5000 rpm |
| Cylinders angle | 60 | 60 | |||
| Maximum Power (HP) | 155 hp | 187 hp | 190 hp | ||
| Power (PS) | 120 ps | 144 ps | 157 ps | 190 ps | 193 ps |
| Power kW | 116 kW | 139 kW | 142 kW | ||
| Power @ rounds per minute | 6300 rpm | 6500 rpm | 6400 rpm | 6300 rpm | 6300 rpm |
| Bore | 82 mm | 82 mm | 83 mm | 88 mm | 88 mm |
| Stroke | 76 mm | 83 mm | 91 mm | 68.3 mm | 68.3 mm |
| Valve Train | Double overhead camshaft DOHC | Double overhead camshaft DOHC | Double overhead camshaft DOHC | ||
| Compression Ratio | 10:1 | 10.3:1 | 10.3:1 | ||
| Engine block material | |||||
| Cylinder head material | |||||
| Fuel System | bosch motronicronic m1 5.5 mpsfi | bosch motronicronic me2.1 mpi | efi | ||
| Coolant | Water | Water | Water | ||
| Engine Data accuracy | |||||
|
156 Sportwagon 1.6 Twin Spark 16v
1
156 1.6 Twin Spark 16v 1 |
156 Sportwagon 1.8 Twin Spark 16v
1
156 1.8 Twin Spark 16v 1 |
156 Sportwagon 2.0 T. Spark
1
156 2.0 Twin Spark 1 |
156 V6
1
156 V6 Q-System 1 |
156 Sportwagon 2.5 V6 24v
1
156 Sportwagon 2.5 V6 Q-System 1 |
| Variants | #SED | #SWG |
|---|---|---|
| Body style | Sedan | Station Wagon / Estate |
| no.Doors | ||
| Wheelbase | 2595 mm | 2595 mm |
| Lenght | 4430 mm | 4430 mm |
| Width | 1745 mm | 1745 mm |
| Height | 1415 mm | 1420 mm |
| Curb Weight | ||
| Wheel Drive | ||
| Engine Location | Front | Front |
| Chassis | ||
| Seating capacity (number) | ||
| Track Tread (front) | 1519 mm | 1519 mm |
| Track Tread (rear) | 1506 mm | 1506 mm |
| Luggage capacity (min) | ||
| Luggage capacity (max) | 378 litres | |
| Weight distribution (FRONT) | ||
| Engine Alignment | Transverse | Transverse |
| Drag Coefficient | ||
| Equipment | ||
|
156 V6
156 V6 Q-System 156 2.0 Twin Spark 156 1.9 JTD 156 1.8 Twin Spark 16v 156 1.6 Twin Spark 16v 156 2.4 JTD |
156 Sportwagon 1.6 Twin Spark 16v
156 Sportwagon 1.9 JTD 156 Sportwagon 2.0 T. Spark 156 Sportwagon 2.4 JTD 156 Sportwagon 2.5 V6 24v 156 Sportwagon 2.5 V6 Q-System 156 Sportwagon 1.8 Twin Spark 16v |
