1978 > 1981
1978 > 1981
| Year | Model Name | Fuel | Body | WheelDrive | Pr.From | to | Speed | QOD | |
|---|---|---|---|---|---|---|---|---|---|
| Year | Model Name | Fuel | Body | WheelDrive | Pr.From | to | Speed | QOD | |
| 1979 | Fiat 131 Diesel 2500 Super Panorama (1979) | Diesel | Sedan | RWD | 0 | 0 | 150 km/h |
|
|
| 1978 | Fiat 131 Panorama 2.0 Diesel Automatic (1978) | Diesel | Sedan | RWD | 0 | 0 | - |
|
|
| 1978 | Fiat 131 Diesel 2500 Super (1978) | Diesel | Sedan | RWD | 0 | 0 | - |
|
|
| 1979 | Fiat 131 Panorama (1979) | Petrol | Sedan | RWD | 0 | 0 | - |
|
|
| 1978 | Fiat 131 Panorama 2.0 Diesel (1978) | Diesel | Sedan | RWD | 0 | 0 | - |
|
|
| 1978 | 1978 Fiat Mirafiori Sport | Petrol | Sedan | RWD | 0 | 0 | 180 km/h |
E
|
|
| 1979 | 1979 Fiat Mirafiori 1300 CL | Petrol | Sedan | RWD | 0 | 0 | - |
E
|
|
| 1979 | Fiat Supermirafiori 1300 | Petrol | Sedan | RWD | 0 | 0 | 160 km/h |
E
|
|
| 1980 | Fiat Supermirafiori 1600 TC | Petrol | Sedan | RWD | 0 | 0 | - |
E
|
|
| 1980 | Fiat Supermirafiori TC Estate | Petrol | Station Wagon / Estate | RWD | 0 | 0 | - |
E
|
| Id.Engine | 1995 cc | 2445 cc |
|---|---|---|
| Kind of Engine | ||
| Identificative engine | ||
| Cylinders Configuration | Straight/Inline Engine | Straight/Inline Engine |
| Displacement | 1995 cc | 2445 cc |
| Cylinders number | 4 | 4 |
| Fuel | Diesel | Diesel |
| Electric engine - kind | ||
| Battery kind | ||
| Peak Power (hp) | ||
| Peak Power (kW) | ||
| Battery power | ||
| Operating Voltage | ||
| Battery: Operating Temperature | ||
| Battery: System Voltage | ||
| Battery: Cell Configuration | ||
| Battery: 0-80% Charge time | ||
| Torque | 113 N-m | 148 N-m |
| Torque @ r.p.m. | 2400 rpm | 2400 rpm |
| Cylinders angle | ||
| Maximum Power (HP) | ||
| Power (PS) | 60 ps | 72 ps |
| Power kW | ||
| Power @ rounds per minute | 4400 rpm | 4200 rpm |
| Bore | 88 mm | 93 mm |
| Stroke | 82 mm | 90 mm |
| Valve Train | ||
| Compression Ratio | 22 | |
| Engine block material | ||
| Cylinder head material | ||
| Fuel System | ||
| Coolant | ||
| Engine Data accuracy | ||
|
131 Panorama 2.0 Diesel Automatic
0
131 Panorama 2.0 Diesel 0 |
131 Diesel 2500 Super Panorama
0
131 Diesel 2500 Super 0 |
| Id.Engine | 1297 cc | 1297 cc | 1297 cc | 1585 cc | 1995 cc |
|---|---|---|---|---|---|
| Kind of Engine | Naturally aspirated | Naturally aspirated | Naturally aspirated | Naturally aspirated | |
| Identificative engine | |||||
| Cylinders Configuration | Straight/Inline Engine | Straight/Inline Engine | Straight/Inline Engine | Straight/Inline Engine | Straight/Inline Engine |
| Displacement | 1297 cc | 1297 cc | 1297 cc | 1585 cc | 1995 cc |
| Cylinders number | 4 | 4 | 4 | 4 | 4 |
| Fuel | Petrol | Petrol | Petrol | Petrol | Petrol |
| Electric engine - kind | |||||
| Battery kind | |||||
| Peak Power (hp) | |||||
| Peak Power (kW) | |||||
| Battery power | |||||
| Operating Voltage | |||||
| Battery: Operating Temperature | |||||
| Battery: System Voltage | |||||
| Battery: Cell Configuration | |||||
| Battery: 0-80% Charge time | |||||
| Torque | 102 N-m | 102 N-m | 103 N-m | 131 N-m | 167 N-m |
| Torque @ r.p.m. | 3000 rpm | 3000 rpm | 4000 rpm | 4000 rpm | 3600 rpm |
| Cylinders angle | |||||
| Maximum Power (HP) | 65 hp | 78 hp | 98 hp | 115 hp | |
| Power (PS) | 65 ps | 66 ps | 79 ps | 99 ps | 117 ps |
| Power kW | 48 kW | 58 kW | 73 kW | 86 kW | |
| Power @ rounds per minute | 5400 rpm | 5200 rpm | 6000 rpm | 6000 rpm | 5800 rpm |
| Bore | 76 mm | 76 mm | 76 mm | 84 mm | 84 mm |
| Stroke | 72 mm | 71.5 mm | 71.5 mm | 71.5 mm | 90 mm |
| Valve Train | Overhead valves OHV | Overhead valves OHV | Double overhead camshaft DOHC | Double overhead camshaft DOHC | |
| Compression Ratio | 9.2:1 | 8.9:1 | 9:1 | 8.9:1 | |
| Engine block material | |||||
| Cylinder head material | |||||
| Fuel System | 1 weber carburettor | 1 weber carburettor | 1 weber carburettor | 1 weber carburettor | |
| Coolant | Water | Water | Water | Water | |
| Engine Data accuracy |
D
| ||||
|
131 Panorama
0
|
Mirafiori 1300 CL
1
|
Supermirafiori 1300
1
|
Supermirafiori 1600 TC
1
Supermirafiori TC Estate 1 |
Mirafiori Sport
1
|
| Variants | #SED | #SED | #SED | #SED | #SED | #SWG |
|---|---|---|---|---|---|---|
| Body style | Sedan | Sedan | Sedan | Sedan | Sedan | Station Wagon / Estate |
| no.Doors | ||||||
| Wheelbase | 2490 mm | 2490 mm | 2489 mm | 2490 mm | 2489 mm | 2490 mm |
| Lenght | 4230 mm | 4230 mm | 4232 mm | 4260 mm | 4262 mm | 4232 mm |
| Width | 1651 mm | 1650 mm | 1664 mm | 1650 mm | 1651 mm | 1651 mm |
| Height | 1384 mm | 1380 mm | 1400 mm | 1410 mm | 1384 mm | 1390 mm |
| Curb Weight | ||||||
| Wheel Drive | ||||||
| Engine Location | Front | Front | Front | Front | Front | Front |
| Chassis | ||||||
| Seating capacity (number) | ||||||
| Track Tread (front) | 1372 mm | 1380 mm | 1384 mm | 1390 mm | 1372 mm | 1377 mm |
| Track Tread (rear) | 1321 mm | 1320 mm | 1326 mm | 1330 mm | 1321 mm | 1318 mm |
| Luggage capacity (min) | ||||||
| Luggage capacity (max) | ||||||
| Weight distribution (FRONT) | ||||||
| Engine Alignment | Longitudinal | Longitudinal | Longitudinal | Longitudinal | Longitudinal | |
| Drag Coefficient | ||||||
| Equipment | ||||||
|
Supermirafiori 1600 TC
|
Supermirafiori 1300
|
Mirafiori Sport
|
131 Diesel 2500 Super Panorama
131 Panorama 2.0 Diesel Automatic 131 Diesel 2500 Super 131 Panorama 131 Panorama 2.0 Diesel |
Mirafiori 1300 CL
|
Supermirafiori TC Estate
|
