2005 > 2007
2005 > 2007
| Year | Model Name | Fuel | Body | WheelDrive | Pr.From | to | Speed | QOD | |
|---|---|---|---|---|---|---|---|---|---|
| Year | Model Name | Fuel | Body | WheelDrive | Pr.From | to | Speed | QOD | |
| 2005 | 2005 Fiat Croma 2.4 Multijet 20v Automatic | Diesel | Station Wagon / Estate | 0 | 0 | - |
E
|
||
| 2005 | 2005 Fiat Croma 1.8 MPI 16v | Petrol | Station Wagon / Estate | UNK | 0 | 0 | - |
E
|
|
| 2005 | 2005 Fiat Croma 1.9 Multijet 16v | Diesel | Station Wagon / Estate | 0 | 0 | - |
E
|
||
| 2005 | 2005 Fiat Croma 1.9 Multijet 16v Automatic | Diesel | Station Wagon / Estate | 0 | 0 | - |
E
|
||
| 2005 | 2005 Fiat Croma 2.2 MPI 16v | Petrol | Station Wagon / Estate | 0 | 0 | - |
E
|
||
| 2005 | 2005 Fiat Croma 2.2 MPI 16v Automatic | Petrol | Station Wagon / Estate | 0 | 0 | - |
E
|
||
| 2005 | 2005 Fiat Croma 1.9 Multijet 8v | Diesel | Station Wagon / Estate | 0 | 0 | - |
E
|
| Id.Engine | 1910 cc | 1910 cc | 2387 cc |
|---|---|---|---|
| Kind of Engine | Turbocharged | Turbocharged | Turbocharged |
| Identificative engine | 939 a 3000 | ||
| Cylinders Configuration | Straight/Inline Engine | Straight/Inline Engine | Straight/Inline Engine |
| Displacement | 1910 cc | 1910 cc | 2387 cc |
| Cylinders number | 4 | 4 | 5 |
| Fuel | Diesel | Diesel | Diesel |
| Electric engine - kind | |||
| Battery kind | |||
| Peak Power (hp) | |||
| Peak Power (kW) | |||
| Battery power | |||
| Operating Voltage | |||
| Battery: Operating Temperature | |||
| Battery: System Voltage | |||
| Battery: Cell Configuration | |||
| Battery: 0-80% Charge time | |||
| Torque | 280 N-m | 320 N-m | 400 N-m |
| Torque @ r.p.m. | 2000 rpm | 2000 rpm | 2000 rpm |
| Cylinders angle | |||
| Maximum Power (HP) | 118 hp | 148 hp | 197 hp |
| Power (PS) | 120 ps | 150 ps | 200 ps |
| Power kW | 88 kW | 110 kW | 147 kW |
| Power @ rounds per minute | 4000 rpm | 4000 rpm | 4000 rpm |
| Bore | 82 mm | 82 mm | 82 mm |
| Stroke | 90.4 mm | 90.4 mm | 90.4 mm |
| Valve Train | Single overhead camshaft SOHC | Double overhead camshaft DOHC | Double overhead camshaft DOHC |
| Compression Ratio | 18:1 | 17.5:1 | 17:1 |
| Engine block material | |||
| Cylinder head material | |||
| Fuel System | multijet direct diesel injection | multijet direct diesel injection | common rail direct diesel injectrion |
| Coolant | Water | Water | Water |
| Engine Data accuracy | |||
|
Croma 1.9 Multijet 8v
1
|
Croma 1.9 Multijet 16v
1
Croma 1.9 Multijet 16v Automatic 1 |
Croma 2.4 Multijet 20v Automatic
1
|
| Id.Engine | 1796 cc | 2198 cc |
|---|---|---|
| Kind of Engine | Naturally aspirated | |
| Identificative engine | z22se | |
| Cylinders Configuration | Straight/Inline Engine | Straight/Inline Engine |
| Displacement | 1796 cc | 2198 cc |
| Cylinders number | 4 | 4 |
| Fuel | Petrol | Petrol |
| Electric engine - kind | ||
| Battery kind | ||
| Peak Power (hp) | ||
| Peak Power (kW) | ||
| Battery power | ||
| Operating Voltage | ||
| Battery: Operating Temperature | ||
| Battery: System Voltage | ||
| Battery: Cell Configuration | ||
| Battery: 0-80% Charge time | ||
| Torque | 125 N-m | 203 N-m |
| Torque @ r.p.m. | 3800 rpm | 4000 rpm |
| Cylinders angle | ||
| Maximum Power (HP) | 145 hp | |
| Power (PS) | 138 ps | 147 ps |
| Power kW | 108 kW | |
| Power @ rounds per minute | 6300 rpm | 5800 rpm |
| Bore | 86 mm | |
| Stroke | 94.6 mm | |
| Valve Train | Double overhead camshaft DOHC | |
| Compression Ratio | 10 | 10:1 |
| Engine block material | ||
| Cylinder head material | ||
| Fuel System | mpfi | |
| Coolant | Water | |
| Engine Data accuracy | ||
|
Croma 1.8 MPI 16v
1
|
Croma 2.2 MPI 16v
1
Croma 2.2 MPI 16v Automatic 1 |
| Variants | #SWG |
|---|---|
| Body style | Station Wagon / Estate |
| no.Doors | |
| Wheelbase | 2700 mm |
| Lenght | 4756 mm |
| Width | 1775 mm |
| Height | 1597 mm |
| Curb Weight | |
| Wheel Drive | |
| Engine Location | Front |
| Chassis | |
| Seating capacity (number) | |
| Track Tread (front) | 1513 mm |
| Track Tread (rear) | 1496 mm |
| Luggage capacity (min) | |
| Luggage capacity (max) | |
| Weight distribution (FRONT) | |
| Engine Alignment | Transverse |
| Drag Coefficient | |
| Equipment | |
|
Croma 2.4 Multijet 20v Automatic
Croma 1.8 MPI 16v Croma 1.9 Multijet 16v Croma 1.9 Multijet 16v Automatic Croma 2.2 MPI 16v Croma 2.2 MPI 16v Automatic Croma 1.9 Multijet 8v |
