1983 > 1987
1983 > 1987
| Year | Model Name | Fuel | Body | WheelDrive | Pr.From | to | Speed | QOD | |
|---|---|---|---|---|---|---|---|---|---|
| Year | Model Name | Fuel | Body | WheelDrive | Pr.From | to | Speed | QOD | |
| 1983 | Fiat 127 (1983) | Petrol | Hatchback | FWD | 0 | 0 | - |
E
|
|
| 1985 | Fiat 127 Panorama | Petrol | Station Wagon / Estate | FWD | 0 | 0 | 135 km/h |
E
|
|
| 1985 | Fiat 127 Diesel Panorama | Diesel | Station Wagon / Estate | FWD | 0 | 0 | 130 km/h | 1 |
E
|
| Id.Engine | 1301 cc |
|---|---|
| Kind of Engine | Naturally aspirated |
| Identificative engine | |
| Cylinders Configuration | Straight/Inline Engine |
| Displacement | 1301 cc |
| Cylinders number | 4 |
| Fuel | Diesel |
| Electric engine - kind | |
| Battery kind | |
| Peak Power (hp) | |
| Peak Power (kW) | |
| Battery power | |
| Operating Voltage | |
| Battery: Operating Temperature | |
| Battery: System Voltage | |
| Battery: Cell Configuration | |
| Battery: 0-80% Charge time | |
| Torque | 74 N-m |
| Torque @ r.p.m. | 3000 rpm |
| Cylinders angle | |
| Maximum Power (HP) | 44 hp |
| Power (PS) | 44.6 ps |
| Power kW | 32.8 kW |
| Power @ rounds per minute | 5000 rpm |
| Bore | 76.1 mm |
| Stroke | 71.5 mm |
| Valve Train | Single overhead camshaft SOHC |
| Compression Ratio | 20:1 |
| Engine block material | |
| Cylinder head material | |
| Fuel System | bosch ve 4/8 f 2500 diesel injection pump |
| Coolant | Water |
| Engine Data accuracy | |
|
127 Diesel Panorama
1
|
| Id.Engine | 903 cc | 1049 cc |
|---|---|---|
| Kind of Engine | Naturally aspirated | |
| Identificative engine | ||
| Cylinders Configuration | Straight/Inline Engine | Straight/Inline Engine |
| Displacement | 903 cc | 1049 cc |
| Cylinders number | 4 | 4 |
| Fuel | Petrol | Petrol |
| Electric engine - kind | ||
| Battery kind | ||
| Peak Power (hp) | ||
| Peak Power (kW) | ||
| Battery power | ||
| Operating Voltage | ||
| Battery: Operating Temperature | ||
| Battery: System Voltage | ||
| Battery: Cell Configuration | ||
| Battery: 0-80% Charge time | ||
| Torque | 64 N-m | 77 N-m |
| Torque @ r.p.m. | 3000 rpm | 3000 rpm |
| Cylinders angle | ||
| Maximum Power (HP) | 49 hp | |
| Power (PS) | 45 ps | 49.7 ps |
| Power kW | 36.5 kW | |
| Power @ rounds per minute | 5600 rpm | 5600 rpm |
| Bore | 65 mm | 76 mm |
| Stroke | 68 mm | 57.8 mm |
| Valve Train | Single overhead camshaft SOHC | |
| Compression Ratio | 9.3:1 | |
| Engine block material | ||
| Cylinder head material | ||
| Fuel System | 1 weber 32 icev 34/150 carburettor | |
| Coolant | Water | |
| Engine Data accuracy |
D
| |
|
127
0
|
127 Panorama
1
|
| Variants | #HAT | #SWG |
|---|---|---|
| Body style | Hatchback | Station Wagon / Estate |
| no.Doors | ||
| Wheelbase | 2230 mm | 2225 mm |
| Lenght | 3720 mm | 3920 mm |
| Width | 1560 mm | 1545 mm |
| Height | 1380 mm | 1425 mm |
| Curb Weight | ||
| Wheel Drive | ||
| Engine Location | Front | Front |
| Chassis | ||
| Seating capacity (number) | ||
| Track Tread (front) | 1284 mm | |
| Track Tread (rear) | 1286 mm | |
| Luggage capacity (min) | 312 litres | |
| Luggage capacity (max) | 1175 litres | |
| Weight distribution (FRONT) | ||
| Engine Alignment | Transverse | |
| Drag Coefficient | ||
| Equipment | ||
|
127
|
127 Panorama
127 Diesel Panorama |
