2004 > 2007
2004 > 2007
| Year | Model Name | Fuel | Body | WheelDrive | Pr.From | to | Speed | QOD | |
|---|---|---|---|---|---|---|---|---|---|
| Year | Model Name | Fuel | Body | WheelDrive | Pr.From | to | Speed | QOD | |
| 2004 | 2004 Honda FR-V 2.0 SE | Petrol | Multi Purpose Vehicle | 0 | 0 | - |
F
|
||
| 2004 | 2004 Honda FR-V 2.2 SE | Diesel | Multi Purpose Vehicle | 0 | 0 | - |
F
|
||
| 2004 | 2004 Honda FR-V 1.7 SE | Petrol | Multi Purpose Vehicle | FWD | 2004 | 2007 | 182 km/h |
B
|
|
| 2005 | Honda FR-V 2.2i-CTDi (2005) | Diesel | Multi Purpose Vehicle | FWD | 0 | 0 | 187 km/h |
F
|
|
| 2006 | Honda FR-V 2.2i CTDi Comfort (2006) | Diesel | Multi Purpose Vehicle | FWD | 2004 | 2007 | - | 1 |
C
|
| 2004 | 2004 Honda FR-V 1.7 Comfort | Petrol | Multi Purpose Vehicle | FWD | 2004 | 2007 | 182 km/h | 1 |
B
|
| Id.Engine | 2204 cc |
|---|---|
| Kind of Engine | Turbocharged |
| Identificative engine | n22a2 |
| Cylinders Configuration | Straight/Inline Engine |
| Displacement | 2204 cc |
| Cylinders number | 4 |
| Fuel | Diesel |
| Electric engine - kind | |
| Battery kind | |
| Peak Power (hp) | |
| Peak Power (kW) | |
| Battery power | |
| Operating Voltage | |
| Battery: Operating Temperature | |
| Battery: System Voltage | |
| Battery: Cell Configuration | |
| Battery: 0-80% Charge time | |
| Torque | 251 N-m |
| Torque @ r.p.m. | 2000 rpm |
| Cylinders angle | |
| Maximum Power (HP) | 138 hp |
| Power (PS) | 140 ps |
| Power kW | 103 kW |
| Power @ rounds per minute | 4000 rpm |
| Bore | 85 mm |
| Stroke | 97.1 mm |
| Valve Train | Single overhead camshaft SOHC |
| Compression Ratio | 16.7:1 |
| Engine block material | |
| Cylinder head material | |
| Fuel System | common rail direct diesel injectrion |
| Coolant | Water |
| Engine Data accuracy | |
|
FR-V 2.2 SE
1
FR-V 2.2i-CTDi 0 FR-V 2.2i CTDi Comfort 0 |
| Id.Engine | 1668 cc | 1998 cc |
|---|---|---|
| Kind of Engine | Naturally aspirated | Naturally aspirated |
| Identificative engine | ||
| Cylinders Configuration | Straight/Inline Engine | Straight/Inline Engine |
| Displacement | 1668 cc | 1998 cc |
| Cylinders number | 4 | 4 |
| Fuel | Petrol | Petrol |
| Electric engine - kind | ||
| Battery kind | ||
| Peak Power (hp) | ||
| Peak Power (kW) | ||
| Battery power | ||
| Operating Voltage | ||
| Battery: Operating Temperature | ||
| Battery: System Voltage | ||
| Battery: Cell Configuration | ||
| Battery: 0-80% Charge time | ||
| Torque | 154 N-m | 192 N-m |
| Torque @ r.p.m. | 4800 rpm | 4000 rpm |
| Cylinders angle | ||
| Maximum Power (HP) | 123 hp | 148 hp |
| Power (PS) | 125 ps | 150 ps |
| Power kW | 92 kW | 110 kW |
| Power @ rounds per minute | 6300 rpm | 6500 rpm |
| Bore | 75 mm | 86 mm |
| Stroke | 94.4 mm | 86 mm |
| Valve Train | Single overhead camshaft SOHC | Double overhead camshaft DOHC |
| Compression Ratio | 9.9:1 | 9.8:1 |
| Engine block material | ||
| Cylinder head material | ||
| Fuel System | honda pgm-fi | honda pgm-fi |
| Coolant | Water | Water |
| Engine Data accuracy |
B
|
D
|
|
FR-V 1.7 SE
1
FR-V 1.7 Comfort 5 |
FR-V 2.0 SE
1
|
| Variants | #MPV |
|---|---|
| Body style | Multi Purpose Vehicle |
| no.Doors | |
| Wheelbase | 2685 mm |
| Lenght | 4285 mm |
| Width | 1810 mm |
| Height | 1610 mm |
| Curb Weight | |
| Wheel Drive | |
| Engine Location | Front |
| Chassis | |
| Seating capacity (number) | |
| Track Tread (front) | 1555 mm |
| Track Tread (rear) | 1575 mm |
| Luggage capacity (min) | 439 litres |
| Luggage capacity (max) | 1049 litres |
| Weight distribution (FRONT) | |
| Engine Alignment | Transverse |
| Drag Coefficient | |
| Equipment | |
|
FR-V 2.0 SE
FR-V 2.2 SE FR-V 1.7 SE FR-V 2.2i-CTDi FR-V 2.2i CTDi Comfort FR-V 1.7 Comfort |
