Generic image of Honda FR-V 2004-2007

Honda FR-V 2.2i-CTDi (2005)

MODEL YEAR: 2005

Data Quality

F

Contributors

rover rover

Park in your virtuagarage

Add to your virtuagarage
Makes » Honda » Honda FR-V » Honda FR-V 2004-2007 » Honda FR-V 2.2i-CTDi (2005)

General

Complete name of the carHonda FR-V 2.2i-CTDi (2005)
Model year2005
Quality of DataF - Poor

Specifications

Body styleMulti Purpose Vehicle
no.Doors5
Wheelbase2685 mm
Lenght4285 mm
Width1810 mm
Height1610 mm
Curb Weight1586 kg
Wheel DriveFront
Engine LocationFront
Seating capacity (number)6
Track Tread (front)1555 mm
Track Tread (rear)1575 mm
Engine AlignmentTransverse
Luggage capacity (min)439 l
Luggage capacity (max)1049 l
Fuel capacity58 l

Engine / Powertrain

Kind of EngineTurbocharged
Cylinders ConfigurationStraight/Inline Engine
Displacement2204 cc
Cylinders number4
Valve TrainSingle overhead camshaft SOHC
Bore85 mm
Stroke97.1 mm
Maximum Power (HP)138 hp
Power (PS)140 PS
Power kW103 kW
Power @ rounds per minute4000 rpm
Torque251 Nm
Torque @ r.p.m.2000 rpm
Compression Ratio16.7:1
FuelDiesel
CoolantWater

Drivetrain & Suspension

Suspensions FrontAnti Roll Bar, Independent, Macpherson strut
Suspensions RearAnti Roll Bar, Double wishbones, Independent
Front BrakesVentilated Disc
Rear BrakesDisc
Transmission typeManual
ClutchSingle dry-clutch friction disc
Fuel capacity58 l
SteeringRack and pinion with power steering

Performances

Top Speed187 km/h
Acceleration 0-100 km/h 10.2 s
Consumption mixed6.4 l/100km

Cars mounting the same engine (produced by Honda)

2005 Honda Civic 2.2 i-CTDi 2004 Honda CR-V 2.2 2006 Honda CR-V 2.2 i-CTDi Honda FR-V 2.2i CTDi (2007) Honda FR-V 2.2i CTDi Comfort (2006) 2004 Honda FR-V 2.2 SE
