Mid Generational Restyling, Model year

Lancia Delta I GEN Facelift II (1986 - 1990)

1986 > 1990

Makes » Lancia » Lancia Delta (1979 - 1999) » Lancia Delta I Generation » Lancia Delta I GEN Facelift II (1986 - 1990)

Main article

Year	Model Name	Fuel	Body	WheelDrive	Pr.From	to	Speed		QOD
Year	Model Name	Fuel	Body	WheelDrive	Pr.From	to	Speed		QOD
1986	1986 Lancia Delta HF 4WD Turbo	Petrol	Hatchback	UNK	0	0	209 km/h		E
1987	1987 Lancia Delta HF 4WD Integrale	Petrol	Hatchback		0	0	-		E
1988	Lancia Delta (1988)	Petrol	Hatchback	FWD	0	0	-		E
1988	Lancia Delta HF Integrale (1988)	Petrol	Hatchback	AWD	0	0	215 km/h	1	C
1989	Lancia Delta 1.9 D (1989)	Diesel	Hatchback	FWD	0	0	-		E
1989	Lancia Delta HF Integrale 8v Cat	Petrol	Hatchback	AWD	0	0	212 km/h	1	C
1989	1989 Lancia Delta HF Integrale 16v	Petrol	Hatchback	AWD	0	0	212 km/h	1	C

» Diesel Engines

Id.Engine	1929 cc
Kind of Engine
Identificative engine
Cylinders Configuration	Straight/Inline Engine
Displacement	1929 cc
Cylinders number	4
Fuel	Diesel
Electric engine - kind
Battery kind
Peak Power (hp)
Peak Power (kW)
Battery power
Operating Voltage
Battery: Operating Temperature
Battery: System Voltage
Battery: Cell Configuration
Battery: 0-80% Charge time
Torque	172 N-m
Torque @ r.p.m.	2400 rpm
Cylinders angle
Maximum Power (HP)
Power (PS)	80 ps
Power kW
Power @ rounds per minute	4200 rpm
Bore	83 mm
Stroke	90 mm
Valve Train
Compression Ratio	21
Engine block material
Cylinder head material
Fuel System
Coolant
Engine Data accuracy
	Delta 1.9 D 0

» Petrol Engines

Id.Engine	1302 cc	1995 cc	1995 cc	1995 cc	1995 cc
Kind of Engine			Turbocharged		Turbocharged
Identificative engine
Cylinders Configuration	Straight/Inline Engine	Straight/Inline Engine	Straight/Inline Engine	Straight/Inline Engine	Straight/Inline Engine
Displacement	1302 cc	1995 cc	1995 cc	1995 cc	1995 cc
Cylinders number	4	4	4	4	4
Fuel	Petrol	Petrol	Petrol	Petrol	Petrol
Electric engine - kind
Battery kind
Peak Power (hp)
Peak Power (kW)
Battery power
Operating Voltage
Battery: Operating Temperature
Battery: System Voltage
Battery: Cell Configuration
Battery: 0-80% Charge time
Torque	105 N-m	225 N-m	294 N-m	304 N-m	298 N-m
Torque @ r.p.m.	3400 rpm	2500 rpm	2750 rpm	3500 rpm	3000 rpm
Cylinders angle
Maximum Power (HP)			178 hp		196 hp
Power (PS)	76 ps	165 ps	180 ps	185 ps	200 ps
Power kW			133 kW		144 kW
Power @ rounds per minute	5800 rpm	5500 rpm	5250 rpm	5300 rpm	5500 rpm
Bore			84 mm	84 mm	84 mm
Stroke			90 mm	90 mm	90 mm
Valve Train			Double overhead camshaft DOHC		Double overhead camshaft DOHC
Compression Ratio	9		7.5:1	8	8:1
Engine block material
Cylinder head material
Fuel System			magneti-marelli weber iaw fuel injection		iaw weber fuel injection
Coolant			Water		Water
Engine Data accuracy	D				C
	Delta 0	Delta HF 4WD Turbo 1	Delta HF Integrale 8v Cat 1	Delta HF 4WD Integrale 1 Delta HF Integrale 0	Delta HF Integrale 16v 1

1 HAT

Variants	#HAT	#HAT	#HAT	#HAT	#HAT	#HAT
Body style	Hatchback	Hatchback	Hatchback	Hatchback	Hatchback	Hatchback
no.Doors
Wheelbase	2480 mm	2474 mm	2474 mm	2480 mm	2480 mm	2480 mm
Lenght	3890 mm	3894 mm	3894 mm	3900 mm	3900 mm	3900 mm
Width	1630 mm	1621 mm	1621 mm	1700 mm	1685 mm	1700 mm
Height	1390 mm	1379 mm		1365 mm	1365 mm	1390 mm
Curb Weight
Wheel Drive
Engine Location	Front	Front	Front	Front	Front	Front
Chassis
Seating capacity (number)
Track Tread (front)		1425 mm		1426 mm	1448 mm	1426 mm
Track Tread (rear)		1405 mm		1406 mm	1440 mm	1406 mm
Luggage capacity (min)
Luggage capacity (max)
Weight distribution (FRONT)
Engine Alignment		Transverse	Transverse	Transverse	Transverse	Transverse
Drag Coefficient
Equipment
	Delta Delta 1.9 D	Delta HF 4WD Integrale	Delta HF 4WD Turbo	Delta HF Integrale 8v Cat	Delta HF Integrale 16v	Delta HF Integrale

Restyling of
