2009 > 2013
2009 > 2013
| Year | Model Name | Fuel | Body | WheelDrive | Pr.From | to | Speed | QOD | |
|---|---|---|---|---|---|---|---|---|---|
| Year | Model Name | Fuel | Body | WheelDrive | Pr.From | to | Speed | QOD | |
| 2011 | 2011 Renault Scenic Energy dCi 130 | Diesel | Multi Purpose Vehicle | FWD | 0 | 0 | - |
|
|
| 2009 | 2009 Renault Scenic 2.0 dCi 160 JZ0L06 | Diesel | Multi Purpose Vehicle | FWD | 0 | 0 | - |
|
|
| 2009 | 2009 Renault Scenic TCe 130 JZ0F06 | Petrol | Multi Purpose Vehicle | FWD | 0 | 0 | - |
|
|
| 2009 | 2009 Renault Scenic 2.0 dCi 150 JZ0Y0E | Diesel | Multi Purpose Vehicle | FWD | 0 | 0 | - |
|
|
| 2009 | 2009 Renault Scenic 1.9 dCi 130 JZ0N06 | Diesel | Multi Purpose Vehicle | FWD | 0 | 0 | - |
|
|
| 2009 | 2009 Renault Scenic 2.0 16v 140 JZ0G0T | Petrol | Multi Purpose Vehicle | FWD | 0 | 0 | - |
|
|
| 2009 | 2009 Renault Scenic 1.6 16v JZ0V06 | Petrol | Multi Purpose Vehicle | FWD | 0 | 0 | - |
|
|
| 2009 | 2009 Renault Scenic 1.9 dCi 130 FAP JZ0J06 | Diesel | Multi Purpose Vehicle | FWD | 0 | 0 | - |
|
|
| 2009 | 2009 Renault Scenic 1.5 dCi 85 JZ0A06 | Diesel | Multi Purpose Vehicle | FWD | 0 | 0 | - |
|
|
| 2009 | 2009 Renault Scenic 1.5 dCi 110 JZ0D06 | Diesel | Multi Purpose Vehicle | FWD | 0 | 0 | - |
|
|
| 2009 | 2009 Renault Scenic 1.5 dCi 105 JZ0B06 | Diesel | Multi Purpose Vehicle | FWD | 0 | 0 | - |
|
|
| 2009 | 2009 Renault Grand Scenic TCe 130 JZ0FA6 | Petrol | Multi Purpose Vehicle | FWD | 0 | 0 | - |
|
|
| 2009 | 2009 Renault Grand Scenic TCe 130 JZ0FB6 | Petrol | Multi Purpose Vehicle | FWD | 0 | 0 | - |
|
|
| 2009 | 2009 Renault Grand Scenic 2.0 dCi 160 FAP JZ0LA6 | Diesel | Multi Purpose Vehicle | FWD | 0 | 0 | - |
|
|
| 2009 | 2009 Renault Grand Scenic 2.0 dCi 160 FAP JZ0LB6 | Diesel | Multi Purpose Vehicle | FWD | 0 | 0 | - |
|
|
| 2009 | 2009 Renault Grand Scenic 2.0 dCi 150 FAP JZ0YBE | Diesel | Multi Purpose Vehicle | FWD | 0 | 0 | - |
|
|
| 2009 | 2009 Renault Grand Scenic 2.0 dCi 150 FAP JZ0YAE | Diesel | Multi Purpose Vehicle | FWD | 0 | 0 | - |
|
|
| 2009 | 2009 Renault Grand Scenic 2.0 16v JZ0GBT | Petrol | Multi Purpose Vehicle | FWD | 0 | 0 | - |
|
|
| 2009 | 2009 Renault Grand Scenic 2.0 16v JZ0GAT | Petrol | Multi Purpose Vehicle | FWD | 0 | 0 | - |
|
|
| 2009 | 2009 Renault Grand Scenic 1.9 dCi 130 FAP JZ0J06/JZ0JA6 | Diesel | Multi Purpose Vehicle | FWD | 0 | 0 | - |
|
|
| 2009 | 2009 Renault Grand Scenic 1.9 dCi 130 JZNN26/JZNN36/JZNN46 | Diesel | Multi Purpose Vehicle | FWD | 0 | 0 | - |
|
|
| 2009 | 2009 Renault Grand Scenic 1.9 dCi 130 FAP JZ0JAD/JZ0JB6 | Diesel | Multi Purpose Vehicle | FWD | 0 | 0 | - |
|
|
| 2009 | 2009 Renault Grand Scenic 1.9 dCi 130 JZMN26/JZMN36/JZMN46 | Diesel | Multi Purpose Vehicle | FWD | 0 | 0 | - |
|
|
| 2009 | 2009 Renault Grand Scenic 1.6 16v JZ0VB6 | Petrol | Multi Purpose Vehicle | FWD | 0 | 0 | - |
|
|
| 2009 | 2009 Renault Grand Scenic 1.6 16v JZ0VA6 | Petrol | Multi Purpose Vehicle | FWD | 0 | 0 | - |
|
|
| 2009 | 2009 Renault Grand Scenic 1.5 dCi 110 JZ0DB6 | Diesel | Multi Purpose Vehicle | FWD | 0 | 0 | - |
|
|
| 2009 | 2009 Renault Grand Scenic 1.5 dCi 110 JZ2D0D/JZ0DA6 | Diesel | Multi Purpose Vehicle | FWD | 0 | 0 | - |
|
|
| 2009 | 2009 Renault Grand Scenic 1.5 dCi 105 JZ2B0D/JZ0BA6 | Diesel | Multi Purpose Vehicle | FWD | 0 | 0 | - |
|
|
| 2009 | 2009 Renault Grand Scenic 1.5 dCi 105 JZ0BB6 | Diesel | Multi Purpose Vehicle | FWD | 0 | 0 | - |
|
|
| 2009 | Renault Scenic 1.6 Joie De Vivre (2009) | Petrol | Multi Purpose Vehicle | FWD | 0 | 0 | 185 km/h |
|
| Id.Engine | 1461 cc | 1461 cc | 1461 cc | 1461 cc | 1598 cc | 1870 cc | 1995 cc | 1995 cc | 1995 cc |
|---|---|---|---|---|---|---|---|---|---|
| Kind of Engine | Turbocharged | Turbocharged | Turbocharged | Turbocharged | Turbocharged | Turbocharged | Turbocharged | Turbocharged | |
| Identificative engine | k9k g 832 | k9k 830 | k9k | r9m | f9q | m9r c 615 | |||
| Cylinders Configuration | Straight/Inline Engine | Straight/Inline Engine | Straight/Inline Engine | Straight/Inline Engine | Straight/Inline Engine | Straight/Inline Engine | Straight/Inline Engine | Straight/Inline Engine | Straight/Inline Engine |
| Displacement | 1461 cc | 1461 cc | 1461 cc | 1461 cc | 1598 cc | 1870 cc | 1995 cc | 1995 cc | 1995 cc |
| Cylinders number | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 |
| Fuel | Diesel | Diesel | Diesel | Diesel | Diesel | Diesel | Diesel | Diesel | Diesel |
| Electric engine - kind | |||||||||
| Battery kind | |||||||||
| Peak Power (hp) | |||||||||
| Peak Power (kW) | |||||||||
| Battery power | |||||||||
| Operating Voltage | |||||||||
| Battery: Operating Temperature | |||||||||
| Battery: System Voltage | |||||||||
| Battery: Cell Configuration | |||||||||
| Battery: 0-80% Charge time | |||||||||
| Torque | 240 N-m | 200 N-m | 240 N-m | 260 N-m | 320 N-m | 300 N-m | 360 N-m | 383 N-m | 380 N-m |
| Torque @ r.p.m. | 2000 rpm | 1750 rpm | 2000 rpm | 1750-2800 rpm | 1750 rpm | 1750 rpm | 2000 rpm | 1800-2500 rpm | 2000 rpm |
| Cylinders angle | |||||||||
| Maximum Power (HP) | 103.5 hp | 84 hp | 108.5 hp | 128.5 hp | 128.5 hp | 148 hp | 148 hp | 158 hp | |
| Power (PS) | 85 ps | 105 ps | 110 ps | 130 ps | 150 ps | 160 ps | |||
| Power kW | 77 kW | 63 kW | 81 kW | 96 kW | 96 kW | 110 kW | 110 kW | 118 kW | |
| Power @ rounds per minute | 4000 rpm | 3750 rpm | 4000 rpm | 4000 rpm | 4000 rpm | 3750 rpm | 3750 rpm | 4000 rpm | 3750 rpm |
| Bore | 76 mm | 76 mm | 76 mm | 76 mm | 80 mm | 80 mm | 84 mm | 84 mm | 84 mm |
| Stroke | 80.5 mm | 80.5 mm | 81 mm | 80.5 mm | 79.5 mm | 93 mm | 90 mm | 90 mm | 90 mm |
| Valve Train | Single overhead camshaft SOHC | Single overhead camshaft SOHC | Single overhead camshaft SOHC | Double overhead camshaft DOHC | Double overhead camshaft DOHC | Double overhead camshaft DOHC | Double overhead camshaft DOHC | Double overhead camshaft DOHC | |
| Compression Ratio | 15.3:1 | 17.6:1 | 15 | 15.5:1 | 15.4:1 | 16.6:1 | 15.5:1 | 16.5:1 | 15.1:1 |
| Engine block material | |||||||||
| Cylinder head material | |||||||||
| Fuel System | common rail direct diesel injectrion | common rail direct diesel injectrion | common rail direct diesel injectrion | common rail direct diesel injectrion | common rail direct diesel injectrion | common rail direct diesel injectrion | common rail direct diesel injectrion | common rail direct diesel injectrion | |
| Coolant | Water | Water | Water | Water | Water | Water | Water | Water | |
| Engine Data accuracy | |||||||||
|
Grand Scenic 1.5 dCi 105
1
Grand Scenic 1.5 dCi 105 1 |
Scenic 1.5 dCi 85
1
|
Scenic 1.5 dCi 105
1
|
Scenic 1.5 dCi 110
1
Grand Scenic 1.5 dCi 110 1 Grand Scenic 1.5 dCi 110 1 |
Scenic Energy dCi 130
1
|
Scenic 1.9 dCi 130
1
Scenic 1.9 dCi 130 FAP 1 Grand Scenic 1.9 dCi 130 FAP 1 Grand Scenic 1.9 dCi 130 1 Grand Scenic 1.9 dCi 130 FAP 1 Grand Scenic 1.9 dCi 130 1 |
Grand Scenic 2.0 dCi 150 FAP
1
Grand Scenic 2.0 dCi 150 FAP 1 |
Scenic 2.0 dCi 160
1
Scenic 2.0 dCi 150 1 |
Grand Scenic 2.0 dCi 160 FAP
1
Grand Scenic 2.0 dCi 160 FAP 1 |
| Id.Engine | 1397 cc | 1598 cc | 1598 cc | 1997 cc |
|---|---|---|---|---|
| Kind of Engine | Turbocharged | Naturally aspirated | ||
| Identificative engine | ||||
| Cylinders Configuration | Straight/Inline Engine | Straight/Inline Engine | Straight/Inline Engine | Straight/Inline Engine |
| Displacement | 1397 cc | 1598 cc | 1598 cc | 1997 cc |
| Cylinders number | 4 | 4 | 4 | 4 |
| Fuel | Petrol | Petrol | Petrol | Petrol |
| Electric engine - kind | ||||
| Battery kind | ||||
| Peak Power (hp) | ||||
| Peak Power (kW) | ||||
| Battery power | ||||
| Operating Voltage | ||||
| Battery: Operating Temperature | ||||
| Battery: System Voltage | ||||
| Battery: Cell Configuration | ||||
| Battery: 0-80% Charge time | ||||
| Torque | 190 N-m | 146 N-m | 161 N-m | 200 N-m |
| Torque @ r.p.m. | 2250 rpm | 3600 rpm | 4400 rpm | 4000 rpm |
| Cylinders angle | ||||
| Maximum Power (HP) | 128.5 hp | 108 hp | ||
| Power (PS) | 130 ps | 110 ps | 114 ps | 141 ps |
| Power kW | 96 kW | 81 kW | ||
| Power @ rounds per minute | 5500 rpm | 6000 rpm | 6000 rpm | 6000 rpm |
| Bore | 78 mm | 79 mm | 78 mm | 85 mm |
| Stroke | 73.1 mm | 81.5 mm | 84 mm | 88 mm |
| Valve Train | Double overhead camshaft DOHC | Double overhead camshaft DOHC | ||
| Compression Ratio | 9.1:1 | 11 | ||
| Engine block material | ||||
| Cylinder head material | ||||
| Fuel System | mpfi | efi | ||
| Coolant | Water | Water | ||
| Engine Data accuracy |
D
| |||
|
Scenic TCe 130
1
Grand Scenic TCe 130 1 Grand Scenic TCe 130 1 |
Scenic 1.6 16v
1
Grand Scenic 1.6 16v 1 Grand Scenic 1.6 16v 1 |
Scenic 1.6 Joie De Vivre
0
|
Scenic 2.0 16v 140
1
Grand Scenic 2.0 16v 1 Grand Scenic 2.0 16v 1 |
