1975 > 1980
1975 > 1980
| Year | Model Name | Fuel | Body | WheelDrive | Pr.From | to | Speed | QOD | |
|---|---|---|---|---|---|---|---|---|---|
| Year | Model Name | Fuel | Body | WheelDrive | Pr.From | to | Speed | QOD | |
| 1975 | Seat 124 D Especial 1430 (1975) | Petrol | Sedan | 0 | 0 | 150 km/h |
C
|
||
| 1975 | Seat 124 D (1975) | Petrol | Sedan | 0 | 0 | 140 km/h |
C
|
||
| 1976 | Seat 124 D Especial 1800 (1976) | Petrol | Sedan | 0 | 0 | - |
E
|
||
| 1976 | Seat 124 D Especial 1600 (1976) | Petrol | Sedan | 0 | 0 | - |
E
|
||
| 1978 | Seat 124 D Especial 2000 (1978) | Petrol | Sedan | 0 | 0 | 180 km/h |
C
|
| Id.Engine | 1197 cc | 1438 cc | 1592 cc | 1756 cc | 1919 cc |
|---|---|---|---|---|---|
| Kind of Engine | Naturally aspirated | Naturally aspirated | |||
| Identificative engine | |||||
| Cylinders Configuration | Straight/Inline Engine | Straight/Inline Engine | Straight/Inline Engine | Straight/Inline Engine | Straight/Inline Engine |
| Displacement | 1197 cc | 1438 cc | 1592 cc | 1756 cc | 1919 cc |
| Cylinders number | 4 | 4 | 4 | 4 | 4 |
| Fuel | Petrol | Petrol | Petrol | Petrol | Petrol |
| Electric engine - kind | |||||
| Battery kind | |||||
| Peak Power (hp) | |||||
| Peak Power (kW) | |||||
| Battery power | |||||
| Operating Voltage | |||||
| Battery: Operating Temperature | |||||
| Battery: System Voltage | |||||
| Battery: Cell Configuration | |||||
| Battery: 0-80% Charge time | |||||
| Torque | 90 N-m | 110.9 N-m | 128 N-m | 151 N-m | 157 N-m |
| Torque @ r.p.m. | 3700 rpm | 3400 rpm | 4000 rpm | 4000 rpm | 3500 rpm |
| Cylinders angle | |||||
| Maximum Power (HP) | |||||
| Power (PS) | 65 ps | 75 ps | 95 ps | 114 ps | 114 ps |
| Power kW | 55 kW | 83.8 kW | |||
| Power @ rounds per minute | 5600 rpm | 5400 rpm | 6000 rpm | 6000 rpm | 6000 rpm |
| Bore | 80 mm | 84 mm | |||
| Stroke | 71.5 mm | 86.6 mm | |||
| Valve Train | Overhead valves OHV | Double overhead camshaft DOHC | |||
| Compression Ratio | 9:1 | 9:1 | |||
| Engine block material | |||||
| Cylinder head material | |||||
| Fuel System | 1 bressel carburettor | 1 weber carburettor | |||
| Coolant | Water | Water | |||
| Engine Data accuracy |
D
|
C
|
C
| ||
|
124 D
0
|
124 D Especial 1430
0
|
124 D Especial 1600
0
|
124 D Especial 1800
0
|
124 D Especial 2000
0
|
| Variants | #SED | #SED |
|---|---|---|
| Body style | Sedan | Sedan |
| no.Doors | ||
| Wheelbase | 2420 mm | 2420 mm |
| Lenght | 4030 mm | 4053 mm |
| Width | 1625 mm | 1611 mm |
| Height | 1420 mm | 1420 mm |
| Curb Weight | ||
| Wheel Drive | ||
| Engine Location | Front | Front |
| Chassis | ||
| Seating capacity (number) | ||
| Track Tread (front) | 1330 mm | 1330 mm |
| Track Tread (rear) | 1300 mm | 1300 mm |
| Luggage capacity (min) | ||
| Luggage capacity (max) | ||
| Weight distribution (FRONT) | ||
| Engine Alignment | ||
| Drag Coefficient | ||
| Equipment | ||
|
124 D
|
124 D Especial 1430
124 D Especial 1800 124 D Especial 1600 124 D Especial 2000 |
