| Year | Model Name | Fuel | Body | WheelDrive | Pr.From | to | Speed | QOD | |
|---|---|---|---|---|---|---|---|---|---|
| Year | Model Name | Fuel | Body | WheelDrive | Pr.From | to | Speed | QOD | |
| 1977 | Volkswagen Polo | Petrol | Hatchback | FWD | 0 | 0 | 152 km/h |
E
|
|
| 1976 | 1976 Volkswagen Polo N | Petrol | Hatchback | FWD | 0 | 0 | 135 km/h |
E
|
|
| 1976 | 1976 Volkswagen Polo 1.3 | Petrol | Hatchback | FWD | 0 | 0 | 153 km/h |
E
|
|
| 1976 | 1976 Volkswagen Polo 1.0 | Petrol | Hatchback | FWD | 0 | 0 | 135 km/h | 1 |
E
|
| 1978 | 1978 Volkswagen Polo GLS | Petrol | Hatchback | FWD | 0 | 0 | 142 km/h |
E
|
| Id.Engine | 895 cc | 1043 cc | 1093 cc | 1093 cc | 1272 cc |
|---|---|---|---|---|---|
| Kind of Engine | Naturally aspirated | Naturally aspirated | Naturally aspirated | ||
| Identificative engine | |||||
| Cylinders Configuration | Straight/Inline Engine | Straight/Inline Engine | Straight/Inline Engine | Straight/Inline Engine | Straight/Inline Engine |
| Displacement | 895 cc | 1043 cc | 1093 cc | 1093 cc | 1272 cc |
| Cylinders number | 4 | 4 | 4 | 4 | 4 |
| Fuel | Petrol | Petrol | Petrol | Petrol | Petrol |
| Electric engine - kind | |||||
| Battery kind | |||||
| Peak Power (hp) | |||||
| Peak Power (kW) | |||||
| Battery power | |||||
| Operating Voltage | |||||
| Battery: Operating Temperature | |||||
| Battery: System Voltage | |||||
| Battery: Cell Configuration | |||||
| Battery: 0-80% Charge time | |||||
| Torque | 61 N-m | 74 N-m | 77 N-m | 83 N-m | 96 N-m |
| Torque @ r.p.m. | 3500 rpm | 2700 rpm | 3000 rpm | 3500 rpm | 3300 rpm |
| Cylinders angle | |||||
| Maximum Power (HP) | 40 hp | 40 hp | 59 hp | ||
| Power (PS) | 40.6 ps | 40.6 ps | 50 ps | 60 ps | 55 ps |
| Power kW | 29.8 kW | 29.8 kW | 44 kW | ||
| Power @ rounds per minute | 5900 rpm | 5300 rpm | 5900 rpm | 6000 rpm | 5400 rpm |
| Bore | 69.5 mm | 75 mm | 70 mm | 69.5 mm | 75 mm |
| Stroke | 59 mm | 59 mm | 72 mm | 72 mm | 72 mm |
| Valve Train | Single overhead camshaft SOHC | Single overhead camshaft SOHC | Single overhead camshaft SOHC | ||
| Compression Ratio | 8:1 | 9.5:1 | 8 | 9.5:1 | 10 |
| Engine block material | |||||
| Cylinder head material | |||||
| Fuel System | 1 solex carburettor | 1 solex carburettor | 1 solex 31 pict-5 carburettor | ||
| Coolant | Water | Water | Water | ||
| Engine Data accuracy | |||||
|
Polo N
1
|
Polo 1.0
1
|
Polo GLS
1
|
Polo
1
|
Polo 1.3
1
|
| Variants | #HAT | #HAT | #HAT | #HAT |
|---|---|---|---|---|
| Body style | Hatchback | Hatchback | Hatchback | Hatchback |
| no.Doors | ||||
| Wheelbase | 2329 mm | 2330 mm | 2330 mm | 2330 mm |
| Lenght | 3505 mm | 3505 mm | 3526 mm | 3650 mm |
| Width | 1560 mm | 1560 mm | 1560 mm | 1580 mm |
| Height | 1334 mm | 1334 mm | 1344 mm | 1350 mm |
| Curb Weight | ||||
| Wheel Drive | ||||
| Engine Location | Front | Front | Front | Front |
| Chassis | ||||
| Seating capacity (number) | ||||
| Track Tread (front) | 1295 mm | 1295 mm | 1296 mm | 1310 mm |
| Track Tread (rear) | 1311 mm | 1311 mm | 1312 mm | 1330 mm |
| Luggage capacity (min) | ||||
| Luggage capacity (max) | ||||
| Weight distribution (FRONT) | ||||
| Engine Alignment | Transverse | Transverse | Transverse | Transverse |
| Drag Coefficient | ||||
| Equipment | ||||
|
Polo N
|
Polo GLS
|
Polo
|
Polo 1.3
Polo 1.0 |
